Patent Reflector COB LED Down Light
- Description:
-
-
COB 2.5''/ 3''/ 4''/ 6''/ 8'' LED Down Light
Patent Reflector, Good light uniformity
Glass Cover, Low thermal resistance, High flux density, Low glare
-
-
Next : Integrated LED Down Light
Advantages● The light sourse uses high-purity Al2O3 as material of the base.So the ability of heat storage and conduction will be enhanced much.
● Professional COB encapsulation skill makes the light softer and more comfortable to avoid the glare effect.
● Driver Outside and Driver Inside. Two types are optional.Applications
Model COB 2.5'' UNDL-COB-C2.5A-5W UNDL-COB-C2.5B-5W UNDL-COB-S2.5-5W Product Size φ85x55mm 90×90×55mm Cut Line φ75±2mm Wattage(w) 5w Glass Type 3mm / frosted LED Chip Type 20x20mil COB LED Qty 0.25W*24pcs CRI >80 Light Output (lm) 400lm_DL/ 375lm_CW/ 350lm_WW Light Effeciency 80lm_DL/ 75lm_CW/ 70lm_WW Color Temp. 6500,4500,3000K Power Supply AC 85-265V Frequency 50/60Hz Power Factor >0.5 View Angle 60° Adjustable Angle Yes Long Life 30,000Hrs 30,000H 30,000H Lumen Maintenance 95% / 5000hrs COB substrate Ceramic Connecting wire VDE 0.5mm2 Material Die casting aluminum Reflector Material 0.3mm electroplating Aluminium Packing Color Box Qty/Ctn 50pcs Carton Size(cm) L57*W37*H23.5 Gross Weight(KGs) 8 8.5 Certificate CE,RoHS Model COB 3'' COB 4'' UNDL-COB-C3-10W UNDL-COB-S3-10W UNDL-COB-C4-15W UNDL-COB-S4-15W Product Size φ125x39mm 116×116×39mm φ158×46mm 152×152×46mm Cut Line φ105±5mm φ140±5mm Wattage(w) 10w 15w Glass Type 3mm / frosted LED Chip Type 20x20mil COB LED Qty 0.25W*56pcs 0.5W*80pcs CRI >80 Light Output (lm) 960lm_DL/ 900lm_CW/ 880lm_WW 1440lm_DL/ 1350lm_CW/ 1320lm_WW Light Effeciency 96lm_DL/ 90lm_CW/ 88lm_WW Color Temp. 6500,4500,3000K Power Supply AC 85-265V Frequency 50/60Hz Power Factor >0.9 View Angle 100° Adjustable Angle No Long Life 30,000Hrs Lumen Maintenance 95% / 5000hrs COB Substrate Ceramic Connecting wire VDE 0.5mm2 Material Die casting aluminum Reflector Material 0.3mm electroplating Aluminium Packing Color Box Qty/Ctn 10pcs Carton Size(cm) L36*W32*H15 L57*W37*H23.5 Gross Weight(KGs) 5.5 6 6 Certificate CE,RoHS Model COB 6'' COB 8'' UNDL-COB-C6-20W UNDL-COB-S6-20W UNDL-COB-C8-30W UNDL-COB-S8-30W Product Size φ188×54mm 180×180×54mm φ234×65mm 226×226×65mm Cut Line φ165±5mm φ205±5mm Wattage(w) 20w 30W Glass Type 3mm / frosted LED Chip Type 24x24mil COB LED Qty 0.5W*64pcs 0.5W*90pcs CRI >80 Light Output (lm) 1920lm_DL/ 1800lm_CW/ 1760lm_WW 2880lm_DL/ 2700lm_CW/ 2640lm_WW Light Effeciency 96lm_DL/ 90lm_CW/ 88lm_WW Color Temp. 6500,4500,3000K Power Supply AC 85-265V Frequency 50/60Hz Power Factor >0.9 View Angle 100° Adjustable Angle No Long Life 30,000Hrs Lumen Maintenance 95% / 5000hrs COB Substrate Ceramic Connecting wire VDE 0.5mm2 Material Die casting aluminum Reflector Material 0.3mm electroplating Aluminium Packing Color Box Qty/Ctn 10pcs 8pcs Carton Size(cm) L44*W37*H21 L52*W36.3*H25.5 Gross Weight(KGs) 8.5 10.5 Certificate CE,RoHS
